The LA Series of actuators by CTW Automation is the ultimate in high performance electric linear motion that puts wave form creation and the resulting data collection at your fingertips. While sine waves (accelerating/de-accelerating velocity) and triangles waves (constant velocity) are standard, the LA can achieve “any wave form” drive profiles allowing you to attain a better view into your testing world. Using a simple, Windows based GUI, the User is able to build Test procedures quickly and gather data a few moments later. And because of the actuation methodology motion will be as requested and at a lower operating temperature and lower audible level.
The LA-410 is part of the “10” series of electric linear actuators with a standard 10-inch / 250 mm stroke. Being modular in design, the series builds out in (2), (4) or (6) motor design configurations.
- Usable stroke range of 10 inches / 254 mm
- Peak force of 4,500 lbf.
- Peak Velocity of 200 in/sec (5.00 M/sec)
- ** Please see Specification Sheet for full details **
- Fully Electric – Magnetic linear actuator for instant-on motion and force
- Usable stroke range of 10 inches / 254 mm
- Peak force of 4,500 lbf.
- Peak Velocity of 200 in/sec (5.00 M/sec)
- Optimized motion for cooler and quieter operation
- Sine, Sine-on-Sine, Square, Triangle, Split Velocity and track data and more
- Windows based operating system for simple GUI to operate the actuator
- Input power 208-240 VAC III phase – 60 A
- ** Please see Specification Sheet for full details **
- Longer columns sold in +12” / 305 mm increments
- Safety enclosure / cage
- Hinged door mounted on the left of the enclosure / cage, closed with latch
- option will change crating and shipping
- CE addition for the enclosure / cage
- Enclosure is locked and cannot be opened until machine is disabled
- industry standard double redundant features
- NIST traceable calibrations for force and displacement signals
- Gas assist on the crossbar for a “zero-weight” feel when moving / loading damper
- struts carry the load of the crossbar making it easier to handle
- Side loading mechanism
- pneumatic actuator applying up to 225 lbs. / 1,000 N
- force driven by user within CTW Probe using analog out function
- Additional channels (6) for extra signals / sensors to be collected during operation within CTW Probe
- additional information at end of document
- Digital IO for signaling external devices during the Test sequence
- Used within a CTW Probe Test Sequence this can be used to turn on / off external devices
- Includes 8 total to be configured based on User requirements
- Analog out of Displacement and force signals
- User interface to gather real time signals
- Analog out 0 - 5 VDC
- command driven within CTW Probe software
- Customer can opt to pick-up in Lexington, NC but then NC State tax applies
- Crate – International heat treated
- Shipping – to be determined
- By ground transport in Continental US
- International shipping is not a problem
